Installation Overview

Migrating from a Tails-Based SecureDrop

If you are migrating from an older Tails-based SecureDrop, using the separate Secure Viewing Station, Journalist Workstation and Admin Workstation USB drives, then skip to the Migration Overview.

Setting Expectations

SecureDrop is a technical tool. It is designed to protect journalists and sources, but no tool can guarantee safety. This guide will instruct you in installing and configuring SecureDrop, but it does not explain how to use it safely and effectively. Put another way: at the end of this guide, you will have built a car; you will not know how to drive. The Deployment Guide contains best practices for working with SecureDrop. Make sure to read it after completing the installation.

Setting up SecureDrop is a multi-step process, where each step builds on the steps that come before it. It’s important that you treat the installation as a complete process, making sure not to skip any portions of the install guide or jump ahead to later content.

Once you have all the necessary hardware, setting up SecureDrop will take at least a day’s work.

We recommend that you set aside at least a week to complete and test your setup.

Tracking your progress

To assist in the installation process, we offer a SecureDrop Installation Worksheet, which you can print out and complete as you go. Only complete this worksheet on paper, never electronically.

It is critical that you destroy this worksheet when your installation is complete and all of your passphrases have been safely stored in a password manager.

Warning

Remember to destroy the SecureDrop Installation Worksheet after the installation is complete.

Technical Summary

This installation guide will walk you through the process of setting up the computers and services needed for a functional SecureDrop.

During this process, you’ll set up at least four devices:

  • Admin Workstation:

    A laptop running the QubesOS operating system configured as an Admin Workstation, that you use to install and administer SecureDrop on the servers via SSH. If necessary (i.e. in a small newsroom), the same SecureDrop Workstation used for administration may be used as a Journalist Workstation by journalists to decrypt, view, and export submitted documents. For a larger newsroom, you may set up additional Journalist Workstations as needed for journalist use.

  • Application Server:

    An Ubuntu server running two segmented Tor hidden services. The source connects to the Source Interface, a public-facing Tor Onion Service, to send messages and documents to the journalist. The journalist connects to the Journalist Interface, an authenticated Tor Onion Service, using the SeucreDrop Application on a Journalist Workstation to download encrypted documents and respond to sources.

  • Monitor Server:

    An Ubuntu server that monitors the Application Server with OSSEC and sends email alerts.

  • Network Firewall

    A hardware firewall dedicated to your SecureDrop installation.

A summary of the major steps is as follow:

  1. Acquire compatible hardware.

  2. Prepare email accounts and GPG keys for alert e-mails.

  3. Prepare an Admin Workstation laptop.

  4. Set up the KeePassXC password manager on the Admin Workstation.

  5. Install and configure the dedicated network firewall from the Admin Workstation.

  6. Prepare the (Application and Monitor) servers.

  7. Install SecureDrop on the servers from the Admin Workstation.

  8. Complete local configuration of the Admin Workstation.

  9. Create the first Admin user.

  10. Test the installation.

Optionally: #. Prepare additional Journalist Workstations for use by journalists. #. Prepare encrypted USB Export Drives.

Minimum security requirements for a SecureDrop Workstation

A SecureDrop Workstation (either an Admin Workstation or a Journalist Workstation) contains both a copy of the Submission Private Key, and encrypted and decrypted messages and submissions. It’s critical to ensure that appropriate security practices are applied to a SecureDrop Workstation.

  • SecureDrop Workstations should be stored in a secure and locked room, with access restricted to users and administrators. The room may be monitored externally, but there should be no internal monitoring.

  • A wired Internet connection that does not restrict Tor must be available for the SecureDrop Workstation. This connection should either be dedicated to SecureDrop Workstation, or should be on a fully segregated subnet from the rest of the corporate network.

  • Users should not bring other electronic devices into the room, with the exception of smartphones used for 2FA token generation. While in the room, smartphones should be set to airplane mode, and should not be used for any purpose other than 2FA.

Minimum security requirements for the SecureDrop servers

  • The Application and Monitor Servers should be dedicated physical machines, not virtual machines.

  • A trusted location to host the servers. The servers should be hosted in a location that is owned or occupied by the organization to ensure that their legal department can not be bypassed with gag orders.

  • The SecureDrop servers should be on a separate internet connection or completely segmented from the corporate network, such as a dedicated subnet with DENY rules for all traffic to and from the corporate LAN.

  • All traffic from the corporate network should be blocked at the SecureDrop’s point of demarcation.

  • Video monitoring should be recorded of the server area and the organizations safe.

  • An established monitoring plan and incident response plan. Who will receive the OSSEC alerts and what will their response plan be? These should cover technical outages and a compromised environment plan.
